Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode

China Shenzhen Unifiber Technology Co.,Ltd certification
China Shenzhen Unifiber Technology Co.,Ltd certification
I'm Online Chat Now

Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode

Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode
Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode

Large Image :  Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode

Product Details:
Place of Origin: CHINA
Brand Name: UNIFIBER
Certification: ROHS
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Individual packing
Delivery Time: 3~5 business days
Payment Terms: L/C, T/T
Detailed Product Description
Connector: SC LC FC ST Length: Customized
High Light:

fiber optic jumper cables

,

fiber optic network cable

Mode conditioning patch cord is a duplex multimode cord that has a small length of single-mode fiber at the start of the transmission length. The basic principle behind the cord is that you launch your laser into the small section of single-mode fiber, then the other end of the single-mode fiber is coupled to multimode section of the cable with the core offset from the center of the multimode fiber.

This offset point creates a launch that is similar to typical multimode LED launches. By using an offset between the single-mode fiber and the multimode fiber, mode conditioning patch cords eliminate DMD and the resulting multiple signals allowing use of 1000BASE-LX over existing multimode fiber cable systems. Therefore, these mode conditioning patch cords allow customers an upgrade of their hardware technology without the costly upgrade of their fiber plant. Mode conditioning cables are duplex type, in the middle of the cable it is the key part, usually the 3 connectors of the duplex mode conditioning patch cord are multimode types, and the 4th connector is single mode





Applications:

  • Long Haul to Short Haul LX Gigabit Systems
  • Recommended for Multimode cable runs greater than 50 feet
  • Gigabit Ethernet 1000Base-LX (1300nm wavelength)

Features:

  • Eliminates issues related to Differential Mode Delay (DMD)
  • Compliant with IEEE 802.3z
  • Rugged Offset Closure with Consistent Offset
  • Low Insertion Loss (<0.4dB)
  • Available with 62.5/125µm OM1 and 50/125µm OM2 multimode cable
  • Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode 0Customized Length Mode Conditioning Patch Cord Cable LC SC FC ST Mix Singlemode/ Multimode 1
