Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex

China Shenzhen Unifiber Technology Co.,Ltd certification
China Shenzhen Unifiber Technology Co.,Ltd certification
I'm Online Chat Now

Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex

Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex
Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex

Large Image :  Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex

Product Details:
Place of Origin: CHINA
Brand Name: UNIFIBER-OEM
Certification: ROHS
Model Number: SC-FC
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiable
Packaging Details: PE bag
Delivery Time: 3-5days
Payment Terms: T/T, Western Union
Supply Ability: 10000pcs/day
Detailed Product Description
Connector Type: FC/SC/LC/ST/E2000/MTRJ/MU Cable Diameter: 3.0mm
Fiber Count: Simplex Or Duplex Cable Jacket: PVC/LSZH
Fiber: SM Or MM Color: Blue/Gray/Yellow/Aqua
High Light:

fiber optic jumper cables

,

fiber optic network cable

Indoor Rugged Stainless Steel Armored fiber patch cords SC-FC single mode simplex crush-resistant and rodent-resistant

Indoor Armored Patch Cables will allow you to protect your critical and essential fiber optic network with a crush-resistant and rodent-resistant jacket. They are a perfect solution for installs that require extra protection. The jacket contains steel armor, an aramid yarn strength member all while maintaining great flexibility. This allows for the cable to remain extremely flexible while also being crush and rodent resistant. They come available in OM1, OM3, OM4 and Singlemode and we can provide any standard fiber optic connector type such as LC, SC, and ST.



Feature
Stainless steel armor provides good protection against physical damage.
Light weight and flexible with about a 20D (mm) dynamic minimum bend radius, easy to install.
Low insertion loss and high return loss

excellent stability and reliability


Application

Fiber LAN, WAN
Testing equipment
CATV
FTTX, FTTB, FTTC
Optical fiber communication system



Parameters:

Connector
SC,FC,LC,ST,MU,E2000
Polishing
SM/UPC
MM/PC
SM/APC
Insertion Loss(max)
≤0.30dB
≤0.3dB
≤0.30dB
Return Loss(min)
≥50 dB
≥35 dB
≥60 dB
Tensile Strength(N)
Longterm 100;short term:200
Crush Resistance(N/100mm)
Longterm 3000;short term:5000
Durability
<0.20 dB typical change, 1000 matings
Repeatability
≤0.1dB
Storage , Operating Temperature [°C]
-40~+85



Indoor Rugged Armored Fiber Patch Cords Stainless Steel SC-FC Single Mode simplex 0
