Product Details:
Payment & Shipping Terms:
|
| Product: | Polarization Insensitive Optical Circulator | Ports: | 3 Ports Or 4 Ports |
|---|---|---|---|
| Wavelength: | 1310nm 1550nm 1625nm C+L Band | Pigtail: | 900um |
| Pigtail Length: | 0.5m | Connector: | FC/SC/ST/LC Or Others |
| High Light: | CATV Insensitive Optical Circulator,1625nm Insensitive Optical Circulator,Three Port Polarization Fiber Circulator |
||
The 3 port optical circulator is a compact high performance light wave component that transmits the incoming signal from port 1 to port 2, while transmitting another incoming signal from port 2 to port 3. The component provides high isolation, low insertion loss, high extinction ratio, and excellent environment stability.
Features:
Low insertion loss
Wide band high isolation
Low PDL
Compact in-line package
High stability and reliability
Epoxy free optical path
Applications:
CATV system
Telecommunication network system
Metro/Access networks
Optical amplifier
Wavelength add / drop
Dispersion compensation
Bi-Direction communication
| Parameter | P Grade | A Grade | |
| Configuration | Port1 to Port 2 to Port 3 | ||
| Operation Wavelength (nm) | 1310±30 or 1550±30 or C+L or 1625±10 | ||
| Insertion Loss (dB) | Typical | 0.6 | 0.8 |
| Maximum | 0.8 | 1.0 | |
| Channel Peak Isolation (dB) | >50 | ||
| Channel Isolation (dB) | >40 (1520nm~1580nm) or >32 (1470nm~1610nm) | ||
| Channel Cross Talk (dB) | >50 | ||
| Polarization Dependent Loss (dB) | <0.2 | ||
| Polarization Mode Dispersion (ps) | <0.1 | ||
| Return Loss (dB) | >50 | ||
| Power Handling (mW) | 500 | ||
| Operating Temperature (°C) | -10 ~ +70 | ||
| Storage Temperature (°C) | -40 ~ +85 | ||
| Dimensions (mm) | Ø5.5 x L50 | ||
Note: 1. All parameters are for device without connectors.
2. Special specifications can be customized according to customer requirements.
