MU/UPC Male to Female Single Mode Optical Attenuator 1dB 2dB 3dB 5dB 7dB 10dB

Large Image : MU/UPC Male to Female Single Mode Optical Attenuator 1dB 2dB 3dB 5dB 7dB 10dB

Product Details:

Place of Origin:	CHINA
Brand Name:	Unifiber or OEM
Certification:	ROHS
Model Number:	MU/UPC Male to Female Optical Attenuator

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Negotiable
Packaging Details:	Blister Case
Delivery Time:	5~8days
Payment Terms:	L/C, T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Product:	MU/UPC Male To Female Single Mode Optical Attenuator	Polish Type:	UPC
Return Loss:	UPC >55dB	Wavelength:	1310nm,1550nm
Attenuation Value:	1dB 2dB 3dB 5dB 7dB 10dB	OEM Brand:	Support

Unifiber Offers High-quality MU/UPC or APC Fixed Value Optical Attenuator with Singlemode or Multimode, Male to Female, the Attenuation value are 1dB 2dB 3dB 5dB 7dB 10dB

Features

Low Back Reflection

Accurate Attenuation

Attenuation ranging from 1dB to 25dB

Application

Data NetworksVideo

CATV &FTTH Networks

Telecommunication Networks

Fiber Optical Communication System

Specification

Specification
Attenuation Range	0-25dB
Attenuation Accuracy	±0.5dB(1dB-10dB)
Attenuation Accuracy	±1.0dB(11dB-25dB)
Available Wavelengths	1310nm,1550nm,1310&1550nm
Wavelength Dependence	<0.3dB Change in insertion loss for 1310-1550nm
Retuen Loss	≥55dB(UPC)
Retuen Loss	≥65dB(APC)
Polarization Dependent Loss	≤0.2dB
Temperature Range	-40-80°C(≤0.2dB in insertion loss)
Humidity Range	±0.2dB Change in 10% to 90% relative Humidity Range
Vibration	≤0.1dB Change between 10Hz to 55Hz
Drop	±0.2dB after 8 drops from 1.8meters onto a hard surface
Maximum Optical Input Power	200mW
