2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC

China Shenzhen Unifiber Technology Co.,Ltd certification
China Shenzhen Unifiber Technology Co.,Ltd certification
I'm Online Chat Now

2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC

2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC
2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC

Large Image :  2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC

Product Details:
Place of Origin: CHINA
Brand Name: UNIFIBER
Certification: ROHS
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Payment Terms: L/C, T/T, Western Union
Detailed Product Description
High Light:

fiber optic cable assembly

,

waterproof cable assembly

ODC Socket / Plug connectors, waterproof, robust and ruggedized, military grade fiber cable assemblies



ODC fiber optic patch cables with extremely robust outdoor connector are designed to withstand harsh environment such as mechanical loads, high thermal exposure, and demanding environments like rain, salt and splash water. It is known for their ease of installation and highest operation safety due to the robust and ruggedized design. ODC military grade cables are installation-friendly for fixed or mobile applications and transmit reliably data over long distances under severe environmental conditions.


Features
100%factory testedassemblies withtraceabletestdata

owenvironmentalsensitivity

Robust fiber-optic connector for 2 and 4 channels with screwed mating mechanism

IP68 protection, salt-mist proof and EMI protection

High shock, vibration, and mechanical resistance

 Broad temperature range and wide range of indoor and outdoor cables

Easy, reliable and cost-effective installation.


Application

Indoor and Outdoor applications

Outdoor & Military communication equipment connection.

Oil field, mine communication connection.

Far transmission wireless base station.

Video Surveillance system

Optical fiber sensor.

Railway signal control

Intelligent substation


Parameters

Fiber Type SM(9/125um)MM(50/125um, 62.5/125um)

Polish UPC APC UPC
Insertion Loss SM:Loss≤0.70dB(Max),Loss≤0.50dB(typical) MM:Loss≤0.50dB(Max),Loss≤0.20dB(typical)

Return Loss UPC≥50dB,APC≥60dB UPC≥20dB
Repeatability 200 times typical change value ≤ 0.20dB
Interchangeability ≤0.20dB
mechanical character Socket / Plug:≤500N (Cable)
Protection level IP67
Fiber count(optional) 2,4
Cable Diameter(optional) 4.0,5.0mm
Jacket Material(optional) LSZH,TPU
Connector Type(optional) Socket / Plug
Operating Temperature -20 ~ +70℃
Storage Temperature -40 ~ +85℃

2/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 02/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 12/4 Fiber Outdoor Cable Connector Waterproof Rugged ODC Cable Assemblies ODC Socket To LC/SC/ST/FC 2
