Full Duplex Channels MTP Sfp Optical Transceiver Multimode

Cisco compatiable 40G QSFP+ SR4 850nm Multimode Transceiver Module 100m

Multi-Mode InfiniBand SDR DDR QDR 40G QSFP+ Transceiver MPO Connector 40G 850nm 100m/300m QSFP SR4 It integrates four data lanes in each direction with 40 Gbps bandwidth. And these modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 38 contact edge type connector. The optical interface uses an 12 fiber MPO connector.

Features :
MTP/MPO optical connector

4 independent full-duplex channels
Up to 11.2Gbps data rate per channel
Capable of over 100m Transmission on OM3 multi-mode ribbon fiber
QSFP MSA compliant
Digital diagnostic capabilities
Single +3.3V power supply
Operating case temperature:0~70C
Maximum 1.5W operation power
RoHS-6 compliant
Compliant with IEEE802.3ba
Compliant with QSFP+ MSA:SFF-8436

Applications :
40G Telecom connections

40G Ethernet
Infiniband 4X SDR DDR QDR

Order Information
