Product Details:
Payment & Shipping Terms:
|
| Product: | SC/APC Fast Connector | Connector: | SC/APC Or SC/UPC |
|---|---|---|---|
| Suitable Cable: | 2.0/3.0 Indoor Cable Or 2.0*3.0mm Drop Cable | Package: | 10pcs/case |
| OEM Brande: | Support | Aplication: | FTTH |
| Highlight: | SC APC Fiber Optic Connectors,No Epoxy Fiber Optic Connectors,FTTH Drop Cable Connectors |
||
1. Description
Field Assmbly SC quick connector can proivide a quick and easy of fiber in the field.Options are avaliable for 900 micron allowing the installer to terminate and make connection in minutes at equipment and fiber patch panels.This connector system removes any requirement for epoxy,adhesive or costly curing ovens and polishing and fiber ederface inspection.
2. Features
♦ Factory-installed fiber stub
♦ No epoxy or polishing required
♦ Quick and easy fiber termination in the field 4.Eliminates cable excess length and pigtail splicestorage
♦ Eliminates cable excess length and pigtail splicestorage
♦ Cost effective
♦ Applicable to bow-type drop cable and 2.0/3.0 indoor cable ,telecom cable
3. Specifications:
| Fast Connector Specification | |||
| Mode | SM | MM | |
| Polish | UPC | APC | PC |
| Insertion Loss |
Typical ≤0.2dB Maximum ≤0.3dB |
≤0.25dB | |
| Return Loss | ≥50dB | ≥65dB | ≥35dB |
| Interchangeability | ≤0.2dB | ||
| Repeatability | ≤0.1dB | ||
| Durability | ≤0.2dB (1000 times mating) | ||
| Tensile Strengh | > 10kg | ||
| Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
| Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
