Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST

China Shenzhen Unifiber Technology Co.,Ltd certification
China Shenzhen Unifiber Technology Co.,Ltd certification
I'm Online Chat Now

Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST

Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST
Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST

Large Image :  Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST

Product Details:
Place of Origin: CHINA
Brand Name: UNIFIBER-OEM
Certification: ROHS
Model Number: Optitap to SC/APC Pre Connectorized Drop Cable
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: PE bag
Delivery Time: 3-5days
Payment Terms: T/T, Western Union
Supply Ability: 10000pcs/day
Detailed Product Description
Connectors: Optitap To SC/APC Pre Connectorized Drop Cable Connector: Optitap SC/APC
Waterproof Grade: IP68 Cable Diameter: 3.0mm,5.0mm Or 7.0mm
Cable Jacket: LSZH,PE,TPU,UV Resistance Cable Length: 1/3/5/10m Or Customized
Fiber: G657A2 Application: FTTA
High Light:

Hardened Optitap Pre Connectorized Cable

,

SC APC Pre Connectorized Cable

,

SST Optical Drop Cable

FTTA Outdoor Waterproof Hardened Optitap to SC/APC Pre Connectorized with SST Drop Cable provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity. The H optic connector end incorporates an SC/APC type connection within a slim, sealed, threaded polymer housing allowing easy connection to either a multiport terminal or in-line extension receptacle. The SC/APC connector mates to a standard adapter, providing a common interface for FTTH applications. Available with flat drop or traditional round style OSP cables, the H optic connector provides an ideal solution for direct burial, conduit, or aerial installations.



Feature
IP-68 water and dust protection;
Bird proof and rodent resistant
Factory terminated for high performance;
Cable Diameter Range: 2.0mm, 3.0mm, 4.8mm to 7mm
Low profile in-line receptacle available;
Easily installs without special tooling


Application

FTTH

FTTA

Outdoor Areas

Harsh Environment



Type
SM-UPC
SM-APC
MM-UPC
Typical
MAX
Typical
MAX
Typical
MAX
Insertion loss
≤0.1
≤0.3dB
≤0.15
≤0.3dB
≤0.05
≤0.3dB
Return loss
≥50dB
≥30dB
≥30dB
Durability
500 mating cycles
Working temperature
-40 to + 85℃


Hardened Optitap SC APC Pre Connectorized Cable FTTA With SST 0
