Product Details:
Payment & Shipping Terms:
|
Product: | FTTH 1*16 PLC Splitter Fibre Terminal Distribution Box Cajas Nap De Distribucion Fibra Optica | Max. Capacity (Single Fiber): | 16 Ports |
---|---|---|---|
Waterproof Grade: | IP68 | Materials: | PC+GF |
Installation Method: | Wall Mounted/Pole Mounted | Sealling: | FTTH |
High Light: | PC GF Fiber Terminal Distribution Box,FTTH Fiber Terminal Distribution Box,PLC Fiber Optic Splicing Closure |
FTTH 1*16 PLC Splitter Fibre Terminal Distribution Box Cajas Nap de Distribucion Fibra Optica can connect the drop cable with feeder cable as the termination point in the Fttx network, which integrates optical splitting and cable distribution, can achieve direct or branch cable connection. It suits the cable distribution of the optical communication equipment. Through the adapter installed in the box, the drop cable leads the signal out, which achieves optical cable distribution; also applies to the protective connection of cables and pigtails.
FEATURES
The body of CTO 16 cores is made of high-quality engineering plastic PP+GF with good strength;
With a safe special-shaped lock, the NAP box can be opened easily and has good waterproof performance, suitable for indoor and outdoor natural environments
With the independent rubber sealing plug for drop cable, better waterproof performance
The splitter 8f box With independent design, the box can be installed and maintained easily, the fusion and termination are completely separated (
The drop leaf can be installed 2 pcs of 1*8 tube splitter
Specification
Model No. | 16 Port Cajas Nap de Distribucion Fibra Optica | Color | Black |
Capacity | 16cores | Protection Level | IP68 |
Material | PP+Glass Fiber | Flame retardant performance | Non-flame retardant |
Dimension(L*W*D,MM) | 380*243*130 | Splitter | Can be with 2x1:8 tube splitter |
