Pre Connectorized Ftth Drop Cable LSZH 150m G657A2 SC APC To SC APC

Pre Connectorized Ftth Drop Cable LSZH 150m G657A2 SC APC To SC APC
Pre Connectorized Ftth Drop Cable LSZH 150m G657A2 SC APC To SC APC Pre Connectorized Ftth Drop Cable LSZH 150m G657A2 SC APC To SC APC

Large Image :  Pre Connectorized Ftth Drop Cable LSZH 150m G657A2 SC APC To SC APC

Product Details:
Place of Origin: China
Brand Name: Unifiber or OEM
Certification: ROHS
Model Number: Pre-connectorized outdoor ftth drop cable patch cord
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiable
Packaging Details: Carton Box
Delivery Time: 3~5 days
Payment Terms: L/C, T/T
Supply Ability: 1000pcs/day
Detailed Product Description
Product: Pre-connectorized Outdoor Ftth Drop Cable Patch Cord Connector: SC/APC Or SC/UPC
Fiber Type: G657A2 Jacket Material: LSZH
Cable Dimension: 2.0*5.0mm Length: 30/50 70/100/150m
Application: FTTH
High Light:

Pre Connectorized Ftth Drop Cable

,

LSZH Ftth Drop Cable

,

G657A2 Ftth Patch Cord

High quality FTTH fiber patch cord SM G657A1 anti bending 10M 30M 50M 100M LSZH. 2.0x5.0mm FTTH drop cable, 2 pcs FRP, blue colored fiber inside, LSZH jacket, assembled with SC / LC / FC / ST connectors.



Features :
1; The connectors are comply with IEC, Telcordia-GR-326-Core standards;
2; Different size & color boot option;
3; Low insertion loss; High return loss;
4; 100% interferometer measurement;
5: Typical IL≤0.20dB;
6. Max IL≤0.25dB;
7. RL SM≥50dB, APC≥60dB, MM≥30dB.
8. Durability(500mating time): IL≤0.25dB.


Application :
1; Telecommunication networks;
2; Local area networks; CATV;
3; Active device termination;
4; Data center system networks;



item
70/100/150m Pre-connectorized outdoor ftth drop cable patch cord G657A2 SC/APC to SC/APC
Optical fiber type
G.657A2
Strength member
two 0.5mm FRP
essenger
1.0mm single FRP messenger
Cable diameter
2.0*5.0mm (±0.1)
Cable material
LSZH
Connector
SC/APC or SC/UPC
Tension(long/short)
300/600N
Crush(long/short)
1000/2000N
Attenuation G.657A after cable (dB/km)@1310/@1550nm
0.3/0.4
Min. Bending radius
10 times cable diameter (Short term)
20 times cable diameter(Long term)
Temperature range
-20℃ to 60℃ (Storage)
