Product: | Indoor Armored Fiber Patch Cord FC/SC/LC/ST | Connector: | FC/SC/LC/ST UPC Or APC |
---|---|---|---|
Cable Diameter: | 3.0mm | Fiber: | G652D Or G657A |
Jacket Material: | LSZH | Color: | Blue |
High Light: | G652D Armored Fiber Patch Cord,3.0mm Armored Fiber Patch Cord,FC SC Singlemode Patch Cord |
Armored fiber patch cable with build-in metal armor can provide stronger protection of the optical fibers than standards fiber optic cables. The rugged armored cables allow optical fiber to be installed in the most hazardous areas, including environments with excessive dust, oil, gas, moisture, or even damage-causing rodents.
Features:
1. The material of Ceramic Ferrule: Zirconium quality stable and easy for polishing
2. Good supply capacity(10K-20K pieces connectors each week)
3. Fast delivery time(3-5 days)
4. Complied to ISO9001 quality system
5. 100% testing before shipment
6. 3D passed testing with report for option
7. All kinds of connector for option(SC,LC,FC,ST,MU,MTRJ,MPO/MTP,ODC,ODLC,and so on)
Application:
1)FTTH, LAN, PON & Optical CATV, Local ring net
2) Optical fiber communication system
3) Optical fiber test equipment
4)Optical fiber sensor
5) Industry and military application
Note:
1.The fiber optic patch cords are available in all connector styles
2.Various color cable available upon customers' request
3.OS2 (9/125um), OM1 (62.5/125um), OM2 (50/125um),
OM3 (50/125um) OM4 (50/125um) OM5 (50/125um) are available.
4.Any length is available upon request.
5.For jacket, PVC (Riser) is normal and LSZH & Plenum are also available.
6.For cable type, G655 & G657 are also available.
Specification:
Pre-Terminated Connector | Singlemode Simplex Indoor Armored Fiber Patch Cord FC/SC/LC/ST |
Polished | UPC or APC |
Fiber Count | 1 or 2 |
Fiber Mode | SingleMode or Multimode |
Jacket Color | Blue |
Breakout OD | 3.0mm |
Insertion Loss | < 0.3 dB |
Return Loss | >50db |
Jacket Materials | LSZH |
Product Keywords | Armored Fiber Opitc Patch Cord |
