Product Details:
Payment & Shipping Terms:
|
| Product: | EPFU Air Blown Fiber Unit | Fiber Counts: | 2/4/6/8/12 Core |
|---|---|---|---|
| Fiber Type: | G657A2 | Suitable Duct: | 3/2.1mm Or 5/3.5mm |
| Sheath Material: | Low Friction HDPE | Blowing Distance: | 500-1000m |
| High Light: | EPFU Air Blown Fiber Cable,Microduct Installation Air Blown Fiber Cable,SM air blown fiber optic cable |
||
Features:
2,4,6,8 and 12 fibres options.
Stable structure, good mechanical and temperature
Designed with special grooves to adavance blowing distance
Light weight and proper stiffness, repeat installation
Designed with no gel, easy stripping and handling.
Better costs advantage compared to traditional product.
Complete accessories, less manpower, lower installation time.
Basic Performance
|
Fibre Count
|
2 Fibres |
4 Fibres |
6 Fibres |
8 Fibres |
12 Fibres |
|
Outer Diameter (mm) |
1.15±0.05 |
1.15±0.05 |
1.35±0.05 |
1.50±0.05 |
1.65±0.05 |
|
Weight (g/m) |
1.0 |
1.0 |
1.3 | 1.8 | 2.2 |
|
Min Bend radius (mm) |
50 | 50 | 60 | 80 | 80 |
|
Temperature |
Storage:-30°C ~ +70°C Operation:-30°C ~ +70°C Installation:-5°C ~ +50°C | ||||
|
Cable service life (estimate value) |
25 years |
||||
