Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft

China Shenzhen Unifiber Technology Co.,Ltd certification
China Shenzhen Unifiber Technology Co.,Ltd certification
I'm Online Chat Now

Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft

Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft
Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft

Large Image :  Toneable Flat Sst Ftth Drop Cable Pre Connectorized G657a2 Optitap To Sc Apc 100ft

Product Details:
Place of Origin: China
Brand Name: Unifiber or OEM
Certification: ROHS
Model Number: Optitap Drop Cable Patch Cord
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 3~5 days
Payment Terms: L/C, T/T
Supply Ability: 500pcs/day
Detailed Product Description
Product: OptiTap SST Toneable Flat Dielectric Drop Cable Connector: Optitap To SC/APC
Fiber: G657A2 Jacket: LSZH/PE
Cable Diameter: 4.5*9.0mm Length: 50F 75F 100F 125F 200F 300F
Application: FTTH
High Light:

toneable ftth drop cable

,

100ft ftth drop cable

,

g657a2 ftth drop fiber optic cable



Toneable mini LT Flat drop cable offers compact, durable, and easy to locate optical fiber solution in a really accessibleconstruction. The fiber optic cable's webbed design allows the locating wire to be easily separated from the main cable sheath by hands, providing simple, rapid routing and grounding of the locating wire. To construct the cable, up to 12 optical fibers are placed in a 2.0mm gel-filled buffer tube to creat a flexible, easy to access core. Then 2 FRP rods are placed diametrically opposite on either side of the fiber core, providing excellent crush resistance and tensile strength during installation and over the lifetime of cable. A 24AWG copper wire is aligned along the outside edge of one of the FRP rods to provide locatability The locating wire, strength member rods, and fiber core are then encapsulated in a durable PE jacket to create a flat cable cross section and lend added protection to the cable core. Between the locating wire and the adjacent FRP rods, the jacket forms a thin web that is easily separated by hand, allowing quick removal of the copper wire from the main sheath.



Features:

​Low insertion loss value
Choice of housing and sleeve materials
Stable capability and high reliability
Excellent mechanical
IP-67 water and dust protection
No installation tools requires
Low profile in-line receptacle available



Application:

Outdoor FTTP, FTTA
Broadband;
Telecom networks
Optical test equipments
Local area networks
Wide area networks



Specification:

Fiber Count
1 core
Fiber Type
SM G652D, SM G657A, or MM 50/125 or MM 62.5/125
Connectors
Optitap Compatible H connector/mini SC/SuperTap SC
Cable Diameter
4.8/7.0mm Round Cable or 3.0*5.5mm Flat Drop Cable
Cable Jacket
LSZH,TPU,PE
Cable Length
1~400m or Customized
