Product Details:
Payment & Shipping Terms:
|
| Product: | FieldShield Pushable Fiber | Connector: | SC/LC |
|---|---|---|---|
| Fiber: | G657A1 | Cable Jacket: | LSZH |
| Packing: | Ziplock Bag/roll Packing | Application: | FTTH |
| High Light: | Field Shield Pushable Fiber Cable,SC/APC Fiber Optical Patch Cord,Less Installation Fiber Optical Patch Cord |
||
FieldShield Pushable Assemblies are factory terminated and polished SC and LC connectors designed to be terminated on simplex and duplex FieldShield Pushable Optical Fiber Assemblies. After being pushed or pulled through FieldShield Microduct, the smooth wall protective sleeve is easily removed and an outer housing is snapped into place. This creates an industry standard connector without mechanical or fusion splicing. All SC and LC FieldShield Pushable Assemblies styles can be pushed/pulled in all FieldShield Microducts.
Designed to simplify the deployment of fiber where one or two fibers are required,
SC Pushable Assemblies provide a tech-friendly field assembled connector that snaps together in seconds without jeopardizing fiber protection or optical reliability. SC Pushable Assemblies greatly reduce installation costs for Fiber to the Home (FTTH) installations, business class services, cell backhaul or any other small count delivery application.
Integrity
Terminations are designed, tested and certified to Telcordia GR-326 and GR-1435
FieldShield fiber cable designed, tested and certified to GR-20
Available in singlemode SC/UPC, SC/APC, Simplex and Duplex LC/UPC, Simplex and Duplex LC/APC
Protection
Smooth wall protective sleeve is easily removed and an outer housing is snapped into place
Option for FlexConnector in YOURx applications
Access
Zirconia ceramic ferrule measuring 1.25 mm O.D.
Tool-less installation
Investment
Tech-friendly pre-terminated pushable fiber connectors rapidly decrease deployment times and reduce installation costs by eliminating in-field splicing
Application
-Designed to simplify the deployment of fiber where one or two fibers are required,
-Provide a tech-friendly field assembled fiber connector that snaps together in seconds without jeopardizing fiber protection or optical reliability. -Greatly reduce installation costs for Fiber to the Home (FTTH) installations, business class services, cell
backhaul or any other small count delivery application
| Connector Type | Ferrule Material | Polish Type | Ins. Loss Typical | Max Ins. Loss | Min. Ret. Loss |
| SC or LC | Ceramic | UPC | 0.15 dB | 0.20 dB | 55.00 dB |
| SC or LC | Ceramic | APC | 0.15 dB | 0.20 dB | 65.00 dB |
