Product Details:
Place of Origin: China
Brand Name: Unifiber or OEM
Certification: ROHS
Model Number: SC/APC Fiber Optical Grating Reflector
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiable
Packaging Details: Blister case
Delivery Time: 3~5 days
Payment Terms: L/C, T/T
Supply Ability: 1000pcs/day
Detailed Product Description
Product: Fiber Optical Grating Reflector 1625nm 1650nm Wavelength: 1625 -1650nm
Connector: SC/APC Male/female Plug Times: 500
Return Loss: 35dB Application: FTTH
High Light:

SC APC Fiber Optical Reflector

,

1625nm Fiber Optical Reflector

,

FTTH Fiber Optical Filter

1650nm fiber grating optical filter is the important components in the field of Optical communications link to detect. The principle is equivalent to a band-pass filter, which completely reflects light from 1643.5nm to 1656.5nm back (the return ratio is over 99.5%) and all other wavelengths of light pass through. Used in the field of communication can be separated communication light (C + L band) and detection of light, to prevent the detection of light through to the communication signal impaction, and can detect the return light at the control. All aspects of fiber grating indicators are stronger than the coating method.



Function
Pass 1310+1550 nm and Stop 1650nm.
RoHS compliance


Features
Reflecta Grating embedded in the fiber, free from environmental pollution;

elength of the reflection band is controlled accurately (1643.5nm ~ 1656.5nm)

g the standard common adapter structure, easy connection.
In the bandpass edge of the transition zone is very narrow (less than 2nm), this area is all-pass;



SC Relector 1650nm Specifications:

Parameters Specification
Wavelength Range(nm) Pass Band 1610-1660
Reflect Band 1260~1360&1460~1581
IL Pass Band dB ≤1.2
Reflect Band dB ≥17
RL Pass Band dB ≥18
Reflect Band dB ≤1.0
PDL(dB)

≤0.3

≤0.15

≤0.15

≤0.2

≤0.25

TDL(dB) ≤0.5
Ripple(dB) ≤0.5
Maximun Optical Power Handing(dBm) 27
Plug Times(Times) 500
Input/Output Connectors SC/APC
Operating Temperature(℃) -20~+75
Storage Temperature(℃) -40~+85



SC APC Fiber Optical Reflector 1625nm 1650nm FTTH Embedded 0SC APC Fiber Optical Reflector 1625nm 1650nm FTTH Embedded 1
